Vertical Shaft Impact Crusher

Vertical Shaft Impact Crusher
Request a Quote
Applications
  • Manufactured sand production Suitable for crushing granite, limestone, river pebbles, and other stone materials into finished sand that meets construction sand standards.
  • Mining operations Used for coarse, medium, or fine crushing of medium- to low-hardness ores such as iron ore and copper ore.
  • Construction waste recycling Processes concrete blocks, waste bricks, and other demolition materials for recycling and resource recovery applications.
  • Road and railway construction Produces aggregates and base materials required for highways, railways, and other infrastructure projects.
  • Metallurgical and chemical processing Suitable for crushing medium- and low-hardness materials such as metallurgical slag and chemical raw materials.
  • Coal mine backfill systems Commonly used for fine crushing of coal gangue in mine backfill and resource utilization projects.
Model Selection and Specifications
Vertical shaft impact crusher (Mainly used for sand making and particle shaping)
Model Capacity (t/h) Max. Feed Size (mm) Motor Power (kW)
LZC-800 30-60 ≤50 55-75
1000 80-150 ≤60 110-132
1200 150-220 ≤70 160-200
1500 220-350 ≤80 250-315
Vertical shaft hammer crusher (For medium-soft material crushing)
Model Capacity (t/h) Max. Feed Size (mm) Motor Power (kW)
LZA-800 12-18 ≤100 30-45
LZA-1000 20-30 ≤150 55-75
LZA-1200 35-50 ≤200 90-110
LZA-1500 50-80 ≤250 132-160
Vertical shaft compound crusher (For fine crushing and pre-grinding)
Model Capacity (t/h) Max. Feed Size (mm) Motor Power (kW)
LZF-800 8-15 ≤80 37-55
LZF-1000 15-25 ≤100 75-90
LZF-1200 25-40 ≤120 110-132
LZF-1500 40-70 ≤150 132-315
